Product Details:
Payment & Shipping Terms:
|
| Materials: | Aluminum Purtity> 99.7% | Tube Volume: | 30ml, 60ml,80ml,5ml - 400ml |
|---|---|---|---|
| Diameter: | 25mm, 12.7mm~40mm | Tube Length: | 125mm, 40mm-200mm |
| Tube Body Thickness: | 0.13mm, (100-210μm) | Screw Thread: | M11 (M7,M9,M11,M13,M15,M17,M19,M21) |
| Highlight: | skin care tube,plastic ointment tubes |
||
1. Cap: White octagonal cap / Black octagonal cap
| Name | Empty hand cream tube |
| Material | Aluminum Purity>99.7%. |
| Diameter | 25mm |
| Volume | 1oz |
| Internal Lacquer color | Expoxy resin |
| Roller Coating | Silver color |
| Printing | Labled paper stickers |
| Nozzle Design | Open tip |
| Caps | Black octagonal cap |
| Screw Thread | M11,M15 |
| Tube Shoulder | polished |
1. Empty Tubes' Dimension:
![]()
| Collapsible Aluminum Tubes Specification Sheet | ||
| Tube Size Diameter | Length Range | Capacity Range |
| 12.5 | 55-75mm | 3-7ml |
| 13.5 | 60-80mm | 3-10ml |
| 16 | 70-110mm | 4-14ml |
| 19 | 70-110mm | 8-20ml |
| 22 | 80-120mm | 9-30ml |
| 25 | 100-160mm | 30-50ml |
| 28 | 100-175mm | 40-80ml |
| 30 | 120-180mm | 50-90ml |
| 32 | 125-190mm | 70-110ml |
| 35 | 125-190mm | 80-180ml |
| 38 | 150-190mm | 90-190ml |
| 40 | 155-210mm | 100-200ml |
| Please Note: The exact capacity varies depending on product formulation and filling machinery. Test Filling of the actual product is suggested to determine the appropriate tube dimension. | ||
3. Widely Usage:
Used for various tube packaging of Pharmaceuticals,Cosmetics,Food,Chemicals,example:,skin-cares,eye ointment,body cream, Hair color cream,Hand Cream,shoe polishcream, toothpaste,herbs,pigment,adhesive glues,food like mustard,chocolate,etc
4. Internal coating for hand cream tube
![]()
